The suction capacity of the YVP 750 vacuum pump is 750 lt / min at 50 kPa (37.5 cm / Hg). The pallet material of the pump is fiber. The vacuum pump is designed to be used in fixed milking systems and it can milk 10 cattle with 220 V 2 Hp, 20 sheep, goat 380 V 3 Hp 12 cattle, 24 sheep and goats. There are 2 Hp - 1500 d / d - 220 V (Single-phase) or 3 Hp-1500 d / d -380 V (Three-phase) electric motor options in the drive of the vacuum pump.

FLOW 750 LT / MIN.

POWER 3 HP (380 V)

PUMP SPEED 1050 D / D.

ELECTRIC MOTOR PULLEY SIZE 17x130xI

PUMP PULLEY SIZE 17x180xI

BODY AND ROTOR CASTING (GG SERIES)

PALLET TYPE FIBER

PALLET SIZE 130x70x5.75 MM.

WEIGHT 44 KG
